| MODEL | 10.2KWH | 12.8KWH | 15.3KWH | 17.9KWH | 20.48KWH |
|---|---|---|---|---|---|
| Nominal Voltage (V) | 204.8 | 256 | 307.2 | 358.4 | 409.2 |
| Nominal Capacity (KWH) | 10.2 | 12.8 | 15.3 | 17.9 | 20.4 |
| Usable Capacity (KWH) | 9.1 | 11.5 | 13.7 | 16.1 | 18.4 |
| Design Life | 10+ Years (25°C / 77°F) | ||||
| PHYSICAL | |||||
| Dimension(mm) | 665*220*1020 | 665*220*1204 | 665*220*1388 | 665*220*1572 | 665*220*1756 |
| Weight(kg) | 125 | 150 | 175 | 200 | 225 |
| ELECTRICAL | |||||
| Cycle Life | >6000 @ 25°C | ||||
| Discharge Voltage (V) | 179.2 | 224 | 268.8 | 313.6 | 358.4 |
| Charge Voltage (V) | 230.4 | 288 | 345.6 | 403.2 | 460.8 |
| Recommend Charge Discharge Current (A) | 25A | ||||
| Max.Charge Max.Charge Discharge Current(A) | 50A | ||||
| Peak Charge Discharge Current(A) | 80A | ||||
| Communication | RS485/CAN | ||||
| OPERATION | |||||
| Working Temperature | 0°C ~ 50°C Charge / -10°C ~ 50°C Discharge | ||||
| Shelf Temperature | -20°C ~ 60°C | ||||
| Certification | CE/IEC/UL/UN38.3/MSDS | ||||
| Design Life | 10 years+ | ||||
