| Modle | 3.6Kwh | 6Kwh | 12Kwh |
| Material | Sheet metal | ||
| Battery | YW Big Single Lithium Iron phosphate Core 3.2V280AH 4S | YW Big Single Lithium Iron phosphate Battery Core 3.2V314AH 6S | Lithium iron phosphate 3.2V314AH 12 string 12056Wh |
| BMS | 350A Active Equalization Software Version BMS | ||
| Charging | Internal 120A charger/2.5 Hour Full | Internal 125A charger/2.5 Hour Full | Internal 120A charger/2.5 Hour Full |
| AC input | Rating 3500W/Peak power 7000W | Rating 4500W/Peak power 9000W | Rating 6500W/Peak power 9000W |
| Driving welder capacity | 2.0/3.2 Welding rod | 2.0/3.2/4.0 Welding rod | 2.0/3.2/4.0 Welding rod |
| Frequency | Automatic follow power frequency 50HZ or 60HZ | ||
| Display screen | LED Module Panel | ||
| LED light | 12W White | ||
| Remote monitoring | Standard 4G module, which can remotely monitor the battery status and remotely switch on and off the machine (GPS and APP optional) | ||
| Standby | Output no-load for 600s, enter into energy-saving automatic shutdown | ||
| Heat Loss | Forced air cooling | ||
| Protective measures | User over charge, over discharge, over-voltage, over-current, short circuit protection, over temperature protection | ||
| Reliability | AC short circuit/overload/over temperature protection and buzzing, DC BMS software protection, no burning, no major fault | ||
| Charge temperature | Zero charge worry free, lower than 0 °C automatically heating to 5 °C before charging | ||
| Discharge temperature | Temperature: -30 °C +60 °C Humidity: 85% | ||
| Storage temperature | Temperature: -20-45 °C | ||
| Protection class | IP53 | ||
| Size | 480*360*530mm | 480*360*530mm | 670*600*450mm |
| Weight | 41kg | 53kg | 91kg |
