| Item | Parameter |
|---|---|
| Model | 601665 |
| Battery Type | Pouch Li-Polymer Battery |
| Nominal Voltage | 3.7V |
| Rated Capacity | 560mAh (2.072Wh) |
| Full Charge Voltage | 4.2V |
| Discharge Cut-off Voltage | 2.75V |
| Dimensions | 6.0×16×65mm |
| Net Weight | Approx. 15g |
| Standard Charge Current | 0.2C (112mA) |
| Max Charge Current | 0.5C (280mA) |
| Continuous Discharge Current | 0.5C (280mA) |
| Peak Discharge Current | 1C (560mA) |
| Optional Parts | Custom JST/Molex Connector, PCM Protection Board |
| Certifications | KC CE, UL, UN38.3, CB |
| Application | Portable device, medical equipment, IoT device, portable power supply |
We support full OEM/ODM to match your exact needs:
We use high-quality PCB to effectively protect the battery during charging and discharging, and integrate NTC temperature management functionality.
We customize battery connectors in various specifications to meet customer requirements. Please provide images or connector part model.
We have strict testing standards covering everything from cell manufacturing to final assembly, ensuring that the batteries are 100% compliant with IEC 62133, UL 2054, and EMC testing standards.
| Model | Voltage | Capacity | Dimensions (mm) |
|---|---|---|---|
| 502065 | 3.7V | 500mAh | 5.0×20×65 |
| 551665 | 3.7V | 520mAh | 5.5×16×65 |
| 552065 | 3.7V | 550mAh | 5.5×20×65 |
| 601230 | 3.7V | 220mAh | 6.0×12×30 |
| 601435 | 3.7V | 300mAh | 6.0×14×35 |
| 601640 | 3.7V | 380mAh | 6.0×16×40 |
| 601650 | 3.7V | 450mAh | 6.0×16×50 |
| 601660 | 3.7V | 500mAh | 6.0×16×60 |
| 601665 | 3.7V | 560mAh | 6.0×16×65 |
| 601670 | 3.7V | 600mAh | 6.0×16×70 |
| 601675 | 3.7V | 650mAh | 6.0×16×75 |
| 601850 | 3.7V | 500mAh | 6.0×18×50 |
| 602030 | 3.7V | 300mAh | 6.0×20×30 |
| 602040 | 3.7V | 400mAh | 6.0×20×40 |
| 602065 | 3.7V | 600mAh | 6.0×20×65 |
| 602530 | 3.7V | 450mAh | 6.0×25×30 |
| 602540 | 3.7V | 520mAh | 6.0×25×40 |
| 603030 | 3.7V | 500mAh | 6.0×30×30 |
| 603040 | 3.7V | 650mAh | 6.0×30×40 |
| 604050 | 3.7V | 1000mAh | 6.0×40×50 |
| 604060 | 3.7V | 1200mAh | 6.0×40×60 |
| 606090 | 3.7V | 4000mAh | 6.0×60×90 |
| 651665 | 3.7V | 620mAh | 6.5×16×65 |
| 701665 | 3.7V | 680mAh | 7.0×16×65 |
| 702065 | 3.7V | 700mAh | 7.0×20×65 |
