Product Description

New Version 5G Telecom Based Station LiFePO4 Battery 48V 20ah 9.6kwh Lithium Battery Pack for Telecommunication System

This series of LiFePO4 batteries adopts high energy density and conversion efficiency lithium technology, offering excellent energy-saving performance and a longer lifespan. It enables smooth site capacity expansion to support 5G evolution, effectively cutting costs and shortening deployment time. Designed with a compact size, high-quality insulation, and robust anti-theft safety locks, these batteries are safer, smarter, and simpler for telecom 5G micro base stations.

Product Features

🛡️ Safer

15+ years of design life with >3000 cycles.
Highly stable LFP cells eliminate fire risks during thermal runaway.
Optional heating and internal insulation for environmental adaptability.
Advanced security locks to prevent theft.
Internal BMS with cell balancing for comprehensive protection.

🧠 Smarter

Automatic protection for overcharge, discharge, and temperature.
Bluetooth APP control reduces O&M costs by 80%.
RS485/CAN communication output for integration.
Real-time power monitoring via APP to extend battery life.
High power density with a 70% smaller footprint than lead-acid batteries.

⚡ Simpler

Fast charging: 1 hour can reach up to 90% capacity.
Maintenance-free throughout the entire lifetime.
Compact design for quick and easy installation.

Product Parameters

Characteristic	EV4805-T	EV4810-T	EV4820-T
Nominal Characteristics
Nominal Voltage	48 V	48 V	48 V
Nominal Capacity	5 Ah	10 Ah	20 Ah
Nominal Energy	240 Wh	480 Wh	960 Wh
Electrical Characteristics
Rec. Charging Voltage	54 V
Max Charging Current	5 A	10 A	20 A
Max Discharging Current	15 A	30 A	60 A
Cycle Life	≥3000 Cycles @ 100% DOD
Mechanical Characteristics
Dimensions (LxWxH)	380x220x145 mm	380x220x145 mm	430x320x150 mm
Weight	8.0 Kg	10 Kg	15 Kg
IP Grade	IP 55

Applications

Base transceiver stations (BTS)
Communication equipment
Telecommunication systems
5G Micro base stations

Service & Logistics

Quality & Service Guarantee
Service	24/7 pre-sales and after-sales support, OEM/ODM available.
Quality	High-reliability production with advanced technology and premium raw materials.
Warranty	Standard 2 years, expandable to 5+ years upon request.
Production	Founded with 30+ years of manufacturing experience; 3,500,000KVAh annual capacity.
Shipping & Payment
Payment	T/T, L/C, Western Union, etc. (Flexible terms).
Delivery Time	Typically 4 weeks ex-factory.
Packing	Carton box on pallets or wooden boxes.

Frequently Asked Questions

Q1: Are you a manufacturer or a trading company? A: We are a professional battery manufacturer with our own facility. We provide comprehensive OEM/ODM services and can produce based on your technical drawings or samples.

Q2: Can I request a sample order? A: Yes, we welcome sample orders to test and verify the quality of our lithium battery solutions.

Q3: How long does it take for delivery? A: Generally, it takes 15-30 days after receiving the advance payment. The specific timeframe depends on the order quantity and item specifications.

Q4: What are your terms of payment? A: Our standard terms are T/T 30% as a deposit and 70% before delivery. We provide photos of products and packaging before final payment.

Q5: Do you test the goods before delivery? A: Yes, we have a professional QC team that ensures every product is in good condition before shipment.

Q6: How is the cycle life of these batteries? A: Our LiFePO4 batteries are designed for a long lifespan, offering more than 3000 cycles at 100% Depth of Discharge (DOD).
